The dream door configurator enabled us to play through different variants and find the perfect entrance door . Our new entrance area is beyond all recognition.
Andrea und Frank Uphoff, Bad Oeynhausen -
Our new entrance door is individual, secure and fits perfectly to the house - and to us.
Stefan und Andrea Vollmers, Hannover -
With the dream door configurator we could realistically show how the entrance will look like. Now we have our individual dream entrance door
Almuth Jordan, Hille -
We uploaded a picture of our facade in the dream door configurator and could see directly what our dream door would look like.
Familie Burg, Hannover -
From configuration to advice from specialist partners to professional installation, we always felt that we are in good hands.
Kai und Christiane Temme, Detmold -
Even our tricky entrance door situation was solved individually and professonally.
Gerd und Krista Wiesbrock, Wiesbaden
Ceramic Art-Corten
charming rust
Optik und Haptik -
wie echter Corten-Stahl
Entrance doors made in Germany –
high-quality, energy efficient and safe
No chance for cold and heat.
Highly insulating thermal insulation core and high-Quality thermal insulation glass: Even the Standard equipment guarantees optimal thermal insulation. If you have special requirements for even greater efficiency, you can choose between further eqipment options.Ask your specialist consultant which thermal insulation package ist best suited to your requirements.
No chance for uninvited guests
With every entrance door panel, you can rely on basic protection and safety. For more protection - for example with extra reinforced surfaces or laminated safety glass - select further equipment together with your specialist consultant. In this way you get exactly the resistance class that lets you sleep most peacefully.
-
Thermal insulation package
Comparable with energy efficiency class A
Insert panel glazed- triple glazing
- inner and outer pane laminated
- Argon gas filling in the space between the panes.
- Insulating core: highly thermal insulating
- Minimum thickness of the panel 36 mm
- U-value of the glass: 0,7 W/m2 K **
- U-value of the complete door panel * including glazing: 0,8 W/m2 K
* / **
Example calculation:
Type 6508-60
insert panel
measure of the panel:
1000x2000x42 mm -
Premium thermal insulation package
Comparable with energy efficiency class A+
One-sided sash overlapping panel, glazed- triple glazing
- inner and outer pane laminated
- Argon gas filling in the space between the panes.
- Insulating core: highly thermal insulating
- Minimum thickness of the panel 36 mm
- U-value of the glass: 0,7 W/m2 K **
- U-value of the complete door panel * including glazing: 0,6 W/m2 K
* / **
Example calculation:
Type 6508-60
sash ovelapping panel
measure of the panel:
1000x2000x56 mm -
Premium plus thermal insulation package
Comparable with Energy Efficiency class A++
Both-sided sash overlapping panel, glazed.- quadruple glazing
- inner and outer pane laminated
- Argon gas filling in the space between the panes.
- Insulating core: highly thermal insulating
- Minimum thickness of the panel 70 mm
- U-value of the glass: 0,5 W/m2 K **
- U-value of the complete door panel * including glazing: 0,4 W/m2 K
* / **
Example calculation
Type 6508-60
sash overlapping panel both-sided
measure of the panel:
1000x2000x90 mm
-
Safety package 1
Resistance class RC1
- Tested safety of the door panel according to valid resistance class RC1N
- External glazing made of 6mm thick laminated safety glass (VSG). The glazing is glued circumferentially into the glass cut.
-
Safety package 2
Resistance class RC2
- Tested safety of the door panel according to valid resistance class RC2
- The outer surface is made of highly resistant material.
- Glazing outside with 10 mm thick laminated safety glass (P4A). The glazing is glued circumferentially into the glass cut out.
-
Safety package 3
Resistance class RC3
- Tested safety of the door panel according to valid resistance class RC3
- The outer surface is made of highly resistant aluminum.
- External glazing made of 10mm thick laminated safety glass (P5A). The glazing is glued circumferentially into the reinforced glass cut.
